50A NEMA 14-50R RV Power Outlet Box with Weatherproof Enclosure and GFCI Protection

5 sets
MOQ
10 USD -15 USD
Price
50A NEMA 14-50R RV Power Outlet Box with Weatherproof Enclosure and GFCI Protection
Features Gallery Product Description Chat Now
Features
Specifications
Conductor Material: Pure Copper
Insulation Material: Teflon
Rated Voltage: 125V
Enclosure Material: Heavy-Gauge Cast Aluminum Or Galvanized Steel
Enclosure Rating: NEMA 3R Or NEMA 4X
Outlet Configuration: 1x 50-amp, 1x 30-amp, 1x 20-amp GFCI
Circuit Protection: Individual Magnetic/Hydraulic Circuit Breakers
Dimensions: 16"H X 12"W X 6"D
Highlight:

NEMA 14-50R RV power outlet

,

weatherproof GFCI outlet box

,

50A RV power enclosure

Basic Infomation
Place of Origin: Shenzhen, Guangdong, China
Brand Name: kenhon
Certification: NEC (National Electrical Code) & UL Standards
Model Number: RV power outlet box
Payment & Shipping Terms
Packaging Details: 10*10*10
Delivery Time: 7-15 days
Payment Terms: L/C,D/A,D/P,T/T
Supply Ability: Can produce 10 million sets of wire harnesses annually
Product Description
Hot 50A EV Camper Trailer Caravans Charging Pile Power Outlet Socket with Weatherproof Enclosure Cover 14-50R 125/250 Volt
RV Power Outlet Box / RV Pedestal Power Center – The Professional-Grade Power Hub for Campgrounds and RV Sites

Product Overview

The RV Power Outlet Box, also commonly known as an RV Pedestal Power Center or Campground Power Pedestal, is a robust, all-in-one electrical distribution unit designed for permanent installation at individual RV campsites, parks, marinas, and private properties. It serves as the centralized, safe, and user-friendly interface between the main electrical supply and the recreational vehicles parked on-site. This unit consolidates multiple high-amperage outlets, circuit protection, and often auxiliary features into a single, durable enclosure, providing reliable and organized power access for RVers of all needs.

Key Features & Benefits (Buyer-Centric Selling Points)
  • Comprehensive, Multi-Service Power Distribution:
    • Dual RV Outlets: Typically includes both a 50-amp (NEMA 14-50R) and a 30-amp (TT-30R) RV receptacle. This allows the pedestal to service everything from the largest luxury motorhomes to smaller travel trailers, maximizing site utility and revenue potential.
    • Standard Household Outlet: Features one or more 20-amp, 125V (NEMA 5-20R) GFCI-protected duplex outlets. This allows campers to safely plug in small appliances, chargers, tools, or outdoor lighting without needing an adapter or running cords into their RV.
  • Superior Safety & Protection Systems:
    • Individual Circuit Breakers: Each outlet is protected by its own dedicated, appropriately rated circuit breaker (e.g., 50A, 30A, 20A). This prevents a fault on one circuit from disabling power to the entire box and provides clear, localized overload protection.
    • GFCI Protection for 120V Circuits: The standard 20-amp outlets are equipped with Ground Fault Circuit Interrupter (GFCI) technology, which instantly cuts power in the event of a ground fault, protecting users from electrical shock—a critical safety feature for outdoor, damp environments.
    • Robust, Lockable Enclosure: Constructed from heavy-duty, weather-resistant materials like cast aluminum or galvanized steel with a powder-coat finish. A lockable, hinged door protects the outlets and breakers from unauthorized access, vandalism, rain, dust, and UV damage.
  • Durable & User-Friendly Design:
    • All-Weather Construction: Rated for outdoor use (NEMA 3R or 4X ratings), capable of withstanding extreme temperatures, moisture, and corrosion. Gasketed doors ensure a weather-tight seal.
    • Clear Labeling & Instructions: Features easy-to-read, permanent labels for each outlet and breaker. Often includes basic usage instructions or a power availability diagram for campers.
    • Integrated Mounting & Cable Management: Designed for easy pole-mounting or post-installation. Some models include a built-in cord hook or wrap to help users keep their power cords organized and off the ground.
  • Convenience & Versatility:
    • Metering Options: Available in standard non-metered versions or with integrated kWh meters. Metered models allow park owners to track and bill for actual electricity usage per site.
    • Lighting: Some premium models include an integrated, protected light fixture for nighttime site illumination.
    • Pre-Wired & Tested: Ships as a complete, pre-assembled unit with internal wiring already connected to terminals, significantly reducing installation time and complexity for electricians.
Detailed Technical Specifications

RV Power Outlet Box / RV Pedestal Power Center

Parameter Specification
Primary ApplicationPermanent power supply station for RV campsites
Enclosure MaterialHeavy-Gauge Cast Aluminum or Galvanized Steel
Enclosure RatingNEMA 3R (Rainproof) or NEMA 4X (Corrosion-Resistant)
FinishPowder-Coated (typically Forest Green, Beige, or Grey)
Outlet Configuration1x 50-amp, 1x 30-amp, 1x 20-amp GFCI (Common Standard)
50A Outlet TypeNEMA 14-50R (125/250V)
30A Outlet TypeTT-30R (125V)
20A Outlet TypeNEMA 5-20R Duplex, GFCI Protected
Circuit ProtectionIndividual Magnetic/Hydraulic Circuit Breakers (e.g., 50A 2-Pole, 30A 2-Pole, 20A 1-Pole)
Voltage120/240V AC, 60Hz (Single-Phase)
Main Feed RequirementTypically 100-amp or 125-amp main service feed per pedestal
Internal WiringCopper, sized per NEC code for each circuit
Enclosure DoorLockable, Hinged, with Gasket Seal
Dimensions (Approx.)Varies by model: e.g., 16"H x 12"W x 6"D
MountingDesigned for 4"x4" or 6"x6" wooden post, or metal pole
MeteringOptional: Built-in Kilowatt-Hour (kWh) meter
ComplianceMeets NEC (National Electrical Code) & UL Standards
Competitive Advantages
  • Maximized Site Revenue & Occupancy: By offering both 50A and 30A service from a single pedestal, you can accommodate any RV that arrives, eliminating turn-aways and maximizing occupancy rates.
  • Professional Installation & Low Maintenance: The pre-wired, rugged design ensures a quick, professional installation and years of reliable, maintenance-free service, reducing lo
